P10 Outdoor LED Billboard 6500cd/sqm Full Color Display

P10 Outdoor LED Billboard 6500cd/sqm Full Color Display

  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
  • P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
P10 Outdoor LED Billboard 6500cd/sqm Full Color Display
Detail produk:
Tempat asal: Guangdong, Cina
Nama merek: kailite p10 outdoor led screen
Nomor model: P10 layar dipimpin luar ruangan
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 12
Kontak
Detil Deskripsi produk
Warna chip tabung: 1R1G1B warna penuh Metode drive: 1/2 pemindaian
Kepadatan fisik: 10000 titik/sqm Tingkat Refresh: 1920HZ-3840HZ
Kecerahan: 6500cd/sqm Daya rata -rata: 450w
Pitch piksel: 10mm Ukuran modul: 320*160mm
Chip LED: SMD3535 Resolusi Modul: 32*16
Kekuatan modul: 70W Sudut pandang: H: 140°; V:140°
Daya maksimum: 900W Ukuran kabinet: W960M × H960mm
Berat: 32kg/panel
Menyoroti:

P10 outdoor LED billboard

,

6500cd/sqm full color display

,

outdoor advertising LED screen

Full Color LED Display Panel P10 P6 Advertising Billboard
Product Specifications
Name P10 LED Billboard
Usage Displaying Videos, Images, Texts
Tube Chip Color 1R1G1B Full Color
Drive Method 1/2 Scan
Physical Density 10000 dots/sqm
Refresh Rate 1920Hz-3840Hz
Warranty 2~3 Years
Brightness 6500cd/sqm
Certificate CE ROHS FCC ISO9001 CCC
Average Power Consumption 450W
Key Features
  • High brightness exceeding 6500cd/m² for clear visibility even in direct sunlight
  • 100% waterproof design for reliable operation in all weather conditions
  • Supports virtually all video file formats, images, and text content
  • 3-year warranty with lifetime maintenance support
P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 0 P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 1 P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 2 P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 3
Technical Parameters
Color Full Color
Use Environment Outdoor
Pixel Pitch 10mm
Module Size 320×160mm
Physical Density 10000 dots/square meter
Pixel Configuration 1R1G1B
LED Chip SMD3535
Module Resolution 32×16
Module Power 70W
Recommended Viewing Distance 10-70m
Best Viewing Angle H: 140°; V:140°
Maximum Power Consumption 900W
Average Power Consumption 450W
Cabinet Size W960mm×H960mm
Standard Cabinet Resolution 96×96
Weight 32kg/panel
Driving Method 1/2 Scan, Constant Current
Video Frame Rate ≥60 Hz
Refresh Rate ≥1200Hz
White Balance Brightness ≥6500cd
Operating Temperature/Humidity -40℃~+65℃
Ingress Protection Front:IP67; Back:IP65
Input Voltage 110-220V AC±10%
Gray Scale/Color Display Colors ≥16.7 Million
Brightness Control Manual/Automatic
Input Signal RF, S-VIDEO, RGBHV, YUV, YC & COMPOSITION, etc.
Control System Asynchronous or Synchronous
MBTF >5000 hours
Life Time >100,000 Hours
The Rate <0.0001
Why Choose Our LED Display Panels
  • Industry Experience: 11 years in LED display manufacturing with 5 years of specialized expertise
  • Comprehensive Support: Full technical support for installation, debugging, and maintenance
  • Reliable Warranty: 2-year warranty with lifetime maintenance service
  • Efficient Solutions: Complete project solutions with proactive issue resolution
  • Cost-Effective Shipping: Competitive rates through established shipping partners
  • Professional Partnership: We treat every client as a valued partner
P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 4 P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 5
Packaging & Shipping
P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 6 P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 7
Frequently Asked Questions
Q1: Are you factory or trading company?

We are a factory with 8000 square meters working plant, and we welcome you to visit our facility.

Q2: What other models do you offer besides P10?

We provide a complete range of indoor and outdoor LED display panels with various pixel pitches to meet different requirements.

Q3: How do I choose the right pixel pitch?

The optimal pixel pitch depends on viewing distance and display size. Our team can help you select the best option for your project.

Q4: What is your lead time?

For orders under 50 square meters, typical lead time is 15-18 working days.

Q5: Do you offer samples?

Yes, we welcome sample orders to evaluate our product quality and service.

Contact Us for Best Price and More Information

Send your inquiry details below and click "Send" now!

P10 Outdoor LED Billboard 6500cd/sqm Full Color Display 8
