P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation

kualitas baik smd layar dipimpin untuk penjualan
kualitas baik smd layar dipimpin untuk penjualan
This is my third time doing business with them, The quality of their led screen is very stable, and have a intimate after service!

—— Nick

I am mykola from Romania. doing business with them is just no worries. they are very considerate, this is what i am always finding

—— Mykola

I 'm Online Chat Now

P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation

Cina P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation pemasok
P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation pemasok P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation pemasok

Gambar besar :  P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation

Detail produk:

Place of Origin: Shenzhen, China(mainland)
Nama merek: OEM/ODM
Sertifikasi: CE,FCC,ROHS ISO9001
Model Number: P5

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity: 2 suqare meter
Harga: Negotiation
Packaging Details: wooden case/ flight case packing
Delivery Time: 5--20 working days
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 8000sqm per month
Contact Now
Detil Deskripsi produk
Pixels: 5mm LED configuration: 1R1G1B
Waterproof: IP65 LED type: SMD 2623,3535,3528
Power Supply: Meanwell or other similar power supply Warranty: 2 years



P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation



Specification



  • For outdoor display, super bright, supports any format of video



  • Easy and simple installation interface and user friendly software to ensure the easy operation the LED display system.



  • Our LED displays are widely used in commercial advertising, indoor led video wall, entertainment industry, stage events, concerts, financial industry, communications, power sector, traffic, stadium, plaza, school, airport et., for advertising and displaying messages.



Product Features



  • Adopting the brightness and hue adjustment technologies, eliminate the bright and dark patches and plagues, realized the color and brightness uniform of the whole display; Taking the HDTV standards as color correction reference, restore nature vivid colors for the whole display.



  • Meticulos design of modules reduce the plane difference to less than 0.2 mm, effectively eliminate the mosaic phenomenon and ensure the excellent flatness and contrast of the whole display.



  • Modular ultra light cabinet with fast lock and dowel pin on it make it quite easy for installation, disassemble and maintain. It can realized lifting or piling installation on site.



  • Cabinet made of good quality pressure-casting aluminum can bear load strength and reduce deformation; it's suitable for large entertainment.



Product Description



LEDs Pixel pitch 5mm
Pixel configuration 1R1G1B
LED type SMD 2623
Wave length Red:620-622.5nm;>280mcd
Green:520-522.5nm;>550mcd
Blue:465-467.5nm;>90mcd
LED manufacturer and origin Epistar
Cabinet Pixels per sqm. 40000 pixels
LEDs qty. per sqm. 40000 pcs
LED module resolution 32x32 pixels
LED module size 320 x160 mm
LED cabinet resolution 128(W) x 128(H) pixels
LED cabinet dimension 640mm(Width)x640mm(Height)
Brightness >6500cd/m2
Viewing angle Horizontal: ≥140°; Vertical: ≥140°
Processing depth 16 bits
Grey scale (linear) 65,536 levels per color
Colors full color
Display refresh rate 1200~2,000 Hz
Scan mode 1/16scan
Power supply Power consumption (max.) ≤1250 watts/sqm
Power consumption (average) ≤450 watts/sqm
Power brand 5V/40A
Input voltage AC 110 or 220 V ±10%
Mechanical design LED cabinet weight 21kg
IC MBI(Optional)
Certifications CE; RoSH, FCC, CCC,ISO
Structure Die-cast Aluminum
ngress protection Front: IP43; Rear: IP43
Serviceability back service



Quality is a soul of an enterprise; Service is a purpose of an enterprise


Our goal is to provide our customers with the highest value of the service and professional solutions.


Pre-sales service


our team design and make solutions based on different requirements from different customers, any special
design we can do, what you can think is what we can do.


After-sales services
1. We provide customer service through Skype, phone or email, provide video or drawing to solve
customer's problem.
2. We provide remote control service through internet to achieve real time service, which will short the
customer problem solving.
3. We provide one professional engineer only for you for fast reply.


Installation Services
1. We provide detailed CAD drawing to customer to prepare metal structure.
2. We could dispatch our engineer to your place help for guide installation and free training.
3. Special designs have special solutions, we will satisfy all customer requirements to make perfect solutions.



FAQ


Indoor vs outdoor



Indoor signs are bright enough to be seen inside a building under commercial lighting, but not bright enough to be seen in direct sunlight. Outdoor signs can be seen in full-on, mid-day sunlight, and are weatherproof to withstand the harsh environmental conditions.



Characters Per Line vs. Lines per Sign


What do you want your message to say? How many words do you need on the screen?



Viewing Distance
How far away is your viewing audience? Are they in their car driving fast on the freeway, or are they strolling casually past your store sipping a latte?



Text vs. Graphics
If you are looking for a simple, easy-to-program, text-only sign, there are plenty of scrolling monochrome and full color models to choose from. If you want full motion graphic animations in addition to scrolling text, then you have to have some method to create the animated content for your display



Color vs. Monochrome
How many colors do you need? Monochrome signs come in red or amber, and can display up to 256 shades of one color (see Nova). High definition RGB displays are capable of displaying up to 4.4 trillion colors!



Viewing Angle vs. Brightness
Viewing Angle is measured in degrees. The wider the angle, the wider the area is that a viewer can read the sign.



What pitch? What resolution? What size?
Resolution refers to the number of LED pixels.



Video vs. Graphics
Do you need graphics or video?



P5 P6 P8 Waterproof HD LED Display Outdoor , LED Video Display Fixed Installation
